March 2020 – Power Electronics for Electric Vehicles

Published on: 03/03/2020

Semikron offers products for every possible application in the automotive environment, discover the power electronics for electric vehicles today

Power Electronics for Electric Vehicles Semikron Image

Electrical vehicles require highly reliable power electronics. Semikron, a leading supplier of power electronics, has bee supplying products to the EV markets for more than 10 years.

From chips and modules to entire converters, the full range of Semikron products can be found in passenger cars, utility vehicles, trucks, buses and industrial and material handling vehicles.

Semikron offers products for every possible application in the automotive environment. The dedicated automotive portfolio includes power modules and systems.



Power Electronics for Electric Vehicles

Semikron’s power modules are found in light duty vehicles such as passenger cars and lightweight trucks up to 7 tons. Semikron’s SEMiX baseplate modules are used by leading Chinese manufacturers of electric vehicles. For higher power density, SKiM63/93 is the first choice for electric as well as plug-in electric vehicles. The SKAI 3 LV, a MOSFET based inverter stack, is perfect for mild hybrid vehicles based on 48VDC bus systems.

For heavy duty vehicles, Semikron offers not only the SEMiX and SKiM63/93 power modules, but also a full inverter system the SKAI 2 HV for up to 850VDC bus. Heavy duty vehicles refer to heavy duty trucks and buses in electric or hybrid configurations.

Battery vehicles, such as forklifts, agricultural and construction vehicles, race cars and motorcycles are powered by SEMiX and SKiM63/93 power modules as well as by the low-voltage MOSFET system SKAI 3 LV.

Semikron’s Key Facts

  • 150,000 SKiM 63/93 drive electric and hybrid buses, passenger cars and electric motorbikes
  • 10,000 buses use SKiM 5 in pre-assembled stacks: power module + driver + heat sink
  • More than 200,000 hybrid and all-electric cars are powered by SEMiX power modules
  • 53,000 SKAI 2 HV drive electric and hybrid buses
  • 1.5 million SKAI LV drive vehicles for material handling



Semikron Electric Vehicle Applications by GD Rectifiers

Power Modules

SKiM63/93

Completely solder-free 6-packs:

  • Maximum reliability in power and thermal cycling tests thanks to sintered chips, AICu wire bonds and pressure contacts
  • Increased power density thanks to baseplate-less module design
  • Hybrid silicon carbide power modules for maximum efficiency and power density
  • Applications: traction inverter



SEMiX 3 Press-fit/SEMiX Spring/SEMiX 5

Baseplate industry standard power module range:

  • Standard high-performance power modules with excellent cost/performance ratio
  • Multiple sourcing thanks to industry standard design
  • Exceeding the standard thanks to packaging design optimisations
  • Applications: traction inverter



SEMITOP E1/E2

The flexible standard:

  • Industry standard baseplate-less package
  • Fully flexible pin-out thanks to the pin-grid structure
  • Customer-specific chipsets, including latest technologies e.g. silicon carbide MOSFETs
  • Applications: on-board chargers, DC/DC converters, compressors, exciters



Systems

SKAI 2 HV

1200V full inverter system

  • Plug and play inverter system up to 250kW and 850VDC bus, 21kVA/l power density
  • Utilising high reliability SKiM 93 power modules
  • Applications: heavy duty vehicles



SKAI 3 LV

Low-voltage system for battery vehicles and mild hybrid electric vehicles

  • Single and dual inverter configuration
  • Up to 50kVA and up to 144V battery voltage
  • Flexible cooling options: water and air-cooled systems possible
  • Applications: battery vehicles



Smeikron Electric Vehicle Products by GD Rectifiers



GD Rectifiers is an authorised distributor for Semikron, offering customers their comprehensive range of semiconductors, power assemblies and heat sinks.

GD Rectifiers stocks Semikron’s complete range of semiconductors, including: diodes, IGBTs, IGBT drivers, MOSFETs, rectifier bridges, SiC hybrid power modules, SiC power modules, thyristors and thyristor/diode modules.

For further information on Semikron’s product range, to to discuss an enquiry, please call GD Rectifiers on: 01444 243 452 or email: enquiries@gdrectifiers.co.uk.
