Low Voltage Fuses

Eaton’s Bussmann low voltage British standard fuses can be used in multiple applications; industrial, utility, street lighting and domestic. Bussmann’s complete range of low voltage fuses are available with compatible fuse holders. Fuses meet the BS88 part 1 and 2 and IEC 60269-1 and -2 standards.

Please note we are still adding products to our new website. Can't see the product you need? Contact us on 01444 243 452 / enquiries@gdrectifiers.co.uk

Expert technical support

Design Inspiration, whenever you need it

Custom & flexible ordering

Filter By

  • Filter By
    Filter By


    Rated Current (A)
    Rated Voltage (V)
    Breaking Capacity (kA)
    Typical Applications
    Industry Approvals

5 results

Sort By:
    • Download Datasheet
    • Parts List
    • Compare
    • Download Datasheet
    • Parts List
    • Compare
    • Download Datasheet
    • Parts List
    • Compare
    • Download Datasheet
    • Parts List
    • Compare
    • Download Datasheet
    • Parts List
    • Compare

Need Fuses Urgently?

Discover our selection of in stock fuses, available with same day or next day delivery.

View Stock List

Low Voltage Fuses

Eaton’s Bussmann Series manufactures over 50,000 part numbers covering extensive circuit protection solutions for a wide range of applications including: residential, industrial, motor protection, power conversion, distribution, telecommunications, electronics and automotive.

Bussmann’s low voltage fuse range offers time-delay, fast-acting, finger-safe and rejection type fuses. The low voltage fuses are used in a large array of applications including specialised circuits, industrial control, small control transformers, electrical panelboards, machinery disconnects and isolated in-line fuse holders.

View the Low Voltage UL & Branch Circuit Fuses Catalogue here.


Class CC

FNQ-R Limitron – 600Vac, 300Vdc, 1/4-30A Datasheet

KTK-R Limitron – 600Vac (or less), 1/10–30A Datasheet

LP-CC Low Peak – 600Vac/300Vdc, 1/2-30A Datasheet


Class CF CUBEFuse

Fast-acting CUBEFuse – 600Vac/dc, 1-100A Datasheet

Time-delay CUBEFuse – 600Vac (or less), 300 Vdc (or less), 1-100A Datasheet

Wind CUBEFuse – 690Vac, 1-100A Datasheet


Class G

600Vac/170Vdc (1/2-20A)

480Vac/300Vdc (25-60A)



Class J

DFJ Drive Fuses – 600Vac (or less), 450Vdc (or less 15,600A), 1-600A Datasheet

JKS Limitron Fast Acting – 600Vac, 1-600A, up to 60A Datasheet, 70-600A Datasheet

LPJ-SP Low-peak – 600Vac, 300Vdc, 1-600A 1-60A Datasheet 70-600A Datasheet


Class K5 and H

NON 250Vac, 125Vdc (1/8-100A)

NOS 600Vac




Class L

KLU Limitron – 600Vac, 601-4000A Datasheet

KRP-C-SP Low-peak – 600Vac, 300Vdc, 601-6000A 601-2000A Datasheet, 2001-6000A Datasheet

KRP-CL – 600Vac (or less), 225-600A Datasheet

KTU Limitron – 600Vac, 601-6000A Datasheet


Class RK1

KTN-R Limitron – 250Vac, 1-600A Datasheet

KTS-R Limitron – 600Vac, 1-600A Datasheet

KWN-R and KWS-R Limitron – 250Vac/dc (KWN-R), 600Vac (KWS-R), 1-60A Datasheet

LPN-RK and LPS-RK Low-peak

LPN-RK: 250V – up to 60A, 250Vdc (70-600A)

LPS-RK: 600Vac – 0-60A, 600Vac – 70-600A


Class RK5

FRN-R Fusetron – 250Vac, 250Vdc (225-600A), 125Vdc (1/10-60A & 110-220A)

FRS-R Fusetron – 600Vac, 300Vdc (1/10-60A & 65-600A), 250Vdc (35-60A)


Class T

JJN Limitron –300Vac (1-10A), 300Vac/160Vdc (15-600A), 300Vac/170Vdc (700-1200A) Datasheet

JJS Limitron – 600Vac, 1-800A Datasheet


Plug Fuses

MB – 125Vac only, 15-20A Catalogue Details

P and TC – 125Vac or less, 15-30A P Datasheet, TC Datasheet

S and T – 125Vac, S Series: 1/4-30A, T Series: 3/10-30A S Datasheet, T Datasheet

SL and TL – 125Vac, 15-30A SL Datasheet, TL Datasheet

W – 125Vac, 1/4-12A Datasheet


For further information Bussmann’s range of low voltage UL and CSA branch circuit fuses please call us on 01444 243 452 or email enquiries@gdrectifiers.co.uk.
