MCC130-16IO2 HT

MCC130-16IO2 Dual Thyristor Module 1600V, 130A

This part is obsolete, please contact our team for a modern day alternative on 01444 243 452 / enquiries@gdrectifiers.co.uk

The MCC130-16IO2 dual thyristor module offers space and weight savings and is designed to meet the general requirements of power control applications by providing high current handling capabilities.

  • Thyristor for line frequencies
  • Industry standard outline
  • Planar passivated chip
  • Long-term stability of blocking currents and voltages
  • Advanced power cycling

Currently Out of Stock

Get notified when this item is back in stock or contact us for alternatives

Add to wishlist

Expert technical support

Design Inspiration, whenever you need it

Custom & flexible ordering

The MCC130-16IO2 dual thyristor module simplifies the conventional multilayer module construction by the DCB (Direct Copper Bonding) technique.

The MCC130-16IO2 thyristor module is now obsolete and is not recommended for new designs.

Approvals
RoHS Compliant

Typical Applications

  • Softstart AC motor control
  • Power converters
  • DC motor control
  • AC power control
  • Lighting and temperature control

Refer to manufacturer’s datasheet for full technical information.

RoHS Compliant

Manufacturer

Applications

, , , ,

Maximum Repetitive Reverse Voltage (VRRM)

1600V

Maximum Non-Repetitive Reverse Voltage (VRSM)

1700V

Value for Fusing (I2t)

112.8 kA2s

Forward Voltage Drop (VT)

1.08V

Reverse Current, Drain Current (IR/D)

200μA

Threshold Voltage (VT0)

0.80V

Slope Resistance (rT)

1.5mΩ

Thermal Resistance Junction to Case (RthJC)

0.23 K/W

Thermal Resistance Junction to Heatsink (RthCH)

0.01 K/W

Total Power Dissipation (Ptot)

435W

Maximum Forward Surge Current (ITSM), 45°C 50Hz, 60Hz

4.75kA, 5.13kA

Turn-off Time (Tq)

150μs

Operating Temperature (Top)

-40°C to +100°C

Package/Case

Y4

Mounting Style

Screw Mount

Type

Phase Leg

Product Type

Thyristor Module

Compliance

RoHS Compliant

IXYS Corporation is a global manufacturer of power semiconductors and power modules, based in Colorado, USA.

IXYS is a pioneering manufacturer of semiconductor and IC technology, with a heritage spanning back twenty-five years, they now have over 125 patents and innovations across their extensive product range. The comprehensive product portfolio includes: reverse blocking IGBTs, MOSFET gate drivers, diodes, thyristors, thyristor/diode modules, rectifiers and fast recovery diodes.

IXYS comprises of three divisions: IXYS Corporation, IXYS IC (Clare) and IXYS Colorado. IXYS Corporation is one of the world’s leading power semiconductor manufacturers, they offer a comprehensive range of MOSFETs, Fast Recovery Diodes (FREDs), SCR and Diode Modules, RF Systems, Rectifiers, Power Interface ICs, IGBTs and Thyristors, in discrete and integrated power modules.

The IXYS IC division designs and produces SOI base HVIC’s flexible display drivers, driver IC’s, optically isolated drivers, solid state relays (SSR), isolated AC switches, ocptocouplers, photovoltaic chips and ASIC’s.

IXYS Colorado formerly manufactured Radio Frequency (RF) and Microwave Discrete Semiconductor products, including: RF Amplifiers, RF MOSFETs, Hybrid Modules, RF Drivers and Gunn Diodes. These products are now obsolete but please contact GD Rectifiers if you are require parts from the RF range.

IXYS Semiconductors, Integrated Circuits and RF Systems are used across numerous applications in the transportation, medical, industrial, telecommunications and computing industries. IXYS’ semiconductors generate clean energy, control motors, improve automation, improve medical equipment and electrifies transportation.

IXYS: A Littelfuse Technology

IXYS is a world leading manufacturer of power semiconductors, their product range includes: IGBTs, MOSFETs, thyristors, diodes and semiconductor accessories. IXYS is now part of Littelfuse. Together, IXYS and Littelfuse leverage their combined technology portfolios and expertise to enhance customer value.

Learn more about IXYS products by getting in touch with GD Rectifiers.
