FIN5955.010.M

FIN5955.010.M Differential Inductance Choke

The FIN5955.010.M differential inductance choke provides excellent attenuation to reduce dV/dt and increases motor life.

  • Reduces dV/dt
  • Protection of motor winding insulation and bearings
  • Remote contact indicator
  • Very low power loss
  • Compact dimension due to the parallel installation
  • Only one model for unlimited HP motors

Currently Out of Stock

Get notified when this item is back in stock or contact us for alternatives

Add to wishlist

Expert technical support

Design Inspiration, whenever you need it

Custom & flexible ordering

The differential inductance choke features a very compact design and protects against voltage spikes on the motor.

This series carries CE and UL approvals and offers a current range from 3 to 1100A with unique features including high linearity vs frequency and current, very low operating temperatures and compact dimensions.

Approvals
RoHS Compliant, CE Marked, UL508, caRUus, SCCR by UL508A

Typical Applications

  • High speed motors up to 250 Hz
  • AC motors controlled by variable frequency drives
  • Woodworking machinery
  • Spindle motors closed loop

Refer to manufacturer’s datasheet for full technical information.

CE MarkedRoHS CompliantcaRUusUL508

Manufacturer

Applications

, , ,

Voltage (Vac)

600Vac

Current (A)

10A

Carrier Frequency (kHz)

0-16 kHz

Output Frequency (Hz)

0-250 Hz

Potential Test Voltage Phase to Phase

2400 Vdc (2 sec.)

Potential Test Voltage Phase to Ground

3200 Vdc (2 sec.)

IP Protection

IP20

Climatic Class

-40°C to +85°C

MTBF at 40°C

250 Hrs

Compliance

caRUus, CE Marked, RoHS Compliant, SCCR by UL508A, UL508

The Enerdoor Group is the industry’s international leader in the development and production of Electromagnetic Solutions for automated and industrial machinery.  Enerdoor provides a wide array of solutions for protection of machinery and equipment, CE approval and testing and elimination of noise, improved reliability and reduced downtime. The Enerdoor Group consists of: Eichhoff Elektro, FinMotor and FinLab which all sit under the parent company.

Renowned for it’s high quality and innovative solutions, Enerdoor manufactures an extensive range of EMI filters, RFI filters, motor protection, harmonic filters, line reactors, surge arresters, voltage stabilisers and customised solutions from their Head Offices in North America and Europe.

Enerdoor supply single phase, three phase and surge protection filters designed to reduce conducted electrical interference in control cabinets. Enerdoor has EMC laboratories in the United States, Germany and Switzerland.

Eichhoff’s manufacturing plant is based in Hungary and strongly focuses on product development and EMC measurement. Eichhoff Elektro has over 40 years experience in safety transformers and electronic ignition systems. They manufacture a wide range of: RFI Filters, Sinus Filters, Reactors, Transformers, PCB Transformers and Ignition Systems.

FinMotor’s manufacturing plant and EMC laboratory is based in Italy. FinMotor manufactures Enerdoor’s EMC Filters, High Frequency inductance and Harmonic Filters for the medical and military markets. They manufacture a wide range of RFI Filters, Passive Harmonic Filters, High Current Sinus Filters, High Frequency Impedances, Motor Protection and Snubbers.

FinLab’s laboratory is based in Milan and focuses on EMC measurement (certification, analysis, solutions and training), harmonic measurement (analysis, solutions and training), acoustic measurement, technical construction file and vibration measurements carried out in their anechoic room and mobile laboratories.

Enerdoor

Enerdoor is part of The Enerdoor Group which consists of Enerdoor in North America and Europe; Finmotor and Finlab in Italy; and Eichhoff Elektro in Hungary.

The group is an international leader in the development and production of electromagnetic solutions for automated and industrial machinery.

The broad range of products include: EMI/RFI filters, motor protection, harmonic filters, line reactors, surge arresters, voltage stabilisers and customised solutions.
