VHF85-14IO7 In stock

VHF85-14IO7 Half Controlled Single Phase Rectifier Bridge 1400V, 82A

This part is obsolete, please contact our team for a modern day alternative on 01444 243 452 / enquiries@gdrectifiers.co.uk

The VHF85-14IO7 is a half controlled single phase rectifier bridge with a freewheeling diode and has a voltage of 1400V and a current of 82A. The half controlled single phase rectifier bridge offers improved thermal behaviour, has a low forward voltage drop and is UL listing applied for.

  • Planar passivated chips
  • Space and weight savings
  • Improved temperature and power cycling
  • Package with screw terminals
  • Isolation voltage 3000V
Add to wishlist

Expert technical support

Design Inspiration, whenever you need it

Custom & flexible ordering

Product Details

The VHF85-14IO7 is easy to mount with two screws, offers improved temperature and power cycling and provides space and weight savings.

Bridge rectifiers are popular devices and are known for converting an Alternating Current (AC) input into Direct Current a (DC) output. Diode bridges feature an arrangement of four diodes in a bridge circuit configuration, providing the same polarity of output for either polarity of input.

Approvals
RoHS Compliant, UL listing applied for

Typical Applications

  • DC motor control

Refer to manufacturer’s datasheet for full technical information.

RoHS CompliantUL Recognised

Manufacturer

Applications

Maximum Repetitive Reverse Voltage (VRRM)

1400V

Average DC Output Current (IDAV)

82A

Maximum Surge Forward Current (IFSM)

1500A

Maximum Non-Repetitive Reverse Blocking Voltage (VRSM)

1500V

Reverse Current (IR)

5mA

Forward Voltage Drop (VF)

1.57V

Value for Fusing (I2t)

11200 A2s

RMS Forward Current (IFRMS)

58A

Operating Temperature (TVJ)

-40°C to +125°C

Mounting Style

Screw Mount

Package/Case

FO-F-A

Product Type

Half Controlled Rectifier Bridge, Rectifier Bridge

Compliance

RoHS Compliant, UL listing applied for

IXYS Corporation is a global manufacturer of power semiconductors and power modules, based in Colorado, USA.

IXYS is a pioneering manufacturer of semiconductor and IC technology, with a heritage spanning back twenty-five years, they now have over 125 patents and innovations across their extensive product range. The comprehensive product portfolio includes: reverse blocking IGBTs, MOSFET gate drivers, diodes, thyristors, thyristor/diode modules, rectifiers and fast recovery diodes.

IXYS comprises of three divisions: IXYS Corporation, IXYS IC (Clare) and IXYS Colorado. IXYS Corporation is one of the world’s leading power semiconductor manufacturers, they offer a comprehensive range of MOSFETs, Fast Recovery Diodes (FREDs), SCR and Diode Modules, RF Systems, Rectifiers, Power Interface ICs, IGBTs and Thyristors, in discrete and integrated power modules.

The IXYS IC division designs and produces SOI base HVIC’s flexible display drivers, driver IC’s, optically isolated drivers, solid state relays (SSR), isolated AC switches, ocptocouplers, photovoltaic chips and ASIC’s.

IXYS Colorado formerly manufactured Radio Frequency (RF) and Microwave Discrete Semiconductor products, including: RF Amplifiers, RF MOSFETs, Hybrid Modules, RF Drivers and Gunn Diodes. These products are now obsolete but please contact GD Rectifiers if you are require parts from the RF range.

IXYS Semiconductors, Integrated Circuits and RF Systems are used across numerous applications in the transportation, medical, industrial, telecommunications and computing industries. IXYS’ semiconductors generate clean energy, control motors, improve automation, improve medical equipment and electrifies transportation.

IXYS: A Littelfuse Technology

IXYS is a world leading manufacturer of power semiconductors, their product range includes: IGBTs, MOSFETs, thyristors, diodes and semiconductor accessories. IXYS is now part of Littelfuse. Together, IXYS and Littelfuse leverage their combined technology portfolios and expertise to enhance customer value.

Learn more about IXYS products by getting in touch with GD Rectifiers.

Datasheet

Datasheet

IXYS-VHF85-14io7-Datasheet.pdf

Product Catalogues

Product Catalogues

IXYS IGBTs Product Catalogue

Product Catalogues

IXYS Product Catalogue 2022-2023

Product Catalogues

IXYS Selector Guide 2015

Share Product

Related Products

Our specialist products, components and designs can be found in a wide range of applications around the world. We also partner with customers to design custom components and devices to suit their requirements.

  • Download Datasheet
  • Parts List
  • Compare

VHF85-14IO7 Half Controlled Single Phase Rectifier Bridge 1400V, 82A

VHF85-14IO7 Half Controlled Single Phase Rectifier Bridge 1400V, 82A

  • Parts List
  • Compare

VHF28-06GO5 Half Controlled Single Phase Rectifier Bridge 600V, 28A

VHF28-06GO5 Half Controlled Single Phase Rectifier Bridge 600V, 28A

  • Download Datasheet
  • Parts List
  • Compare

VHF15-16IO5 Half Controlled Single Phase Rectifier Bridge 1600V, 21A
